Hud aliran laminar bersih
Gambaran keseluruhan:
Penutup aliran laminar yang dipurnikan adalah unit pemurnian udara yang boleh menyediakan persekitaran bersih tempatan, Ia boleh dipasang dengan fleksibel di atas titik proses yang memerlukan kebersihan yang tinggi.
Perkataan Kunci:
Maklumat lanjut:
Introduction detail:
Purified laminar flow cover is an air purification unit that provides a local clean environment. It can be flexibly installed above the process point where high cleanliness is required. It can be used alone or in combination to form a strip-shaped clean area.Purified laminar flow cover passes the air through a high-efficiency filter at a certain wind speed to form a uniform flow layer, so that the clean air is vertically unidirectional, thereby ensuring the cleanliness of the process area.
Features:
●The cabinet is made of high quality SUS304 stainless steel, which is easy to clean;
● Top air supply, high efficiency filter efficiency ≥99.99%@0.3um, the operating area purification level is higher than the room cleanliness;
● The inverter adjusts the wind speed ; the button controls the lighting and power.
Parameter:
|
Technical reference |
|
|
Material |
Stainless steel panel |
|
Features |
Hanging type landing support type |
|
Applications |
Precision Machinery, Electronics, Pharmaceuticals, Food, Fine Chemicals Usage, purification |
|
Usage |
purification |
|
Average wind speed |
0.25-0.45m/s (adjustable) |
|
Noise |
≤62dB(A) |
|
Power supply |
220V 50HZ |
|
Certification |
ISO9001:2008; SGS |
Soalan yang kerap ditanya
1
Berapa lama booth perlu berjalan sebelum digunakan?
Menghidupkan dan menjalankan selama minimum 20 minit sebelum digunakan untuk mewujudkan corak aliran udara yang betul dan mencapai tahap kebersihan yang diperlukan.
2
Bagaimana booth berat tekanan negatif berfungsi?
Kawasan kerja beroperasi di bawah tekanan negatif berbanding dengan kawasan latar belakang. Kebersihan statik sama dengan kebersihan kawasan latar belakang. Tutup port knalpot untuk mewujudkan tekanan positif untuk mencapai kebersihan statik Kelas A.
